Rear Suspension Recumbent Trike

SKU: 320

  • Features
    • Lightweight and durable aluminum frame
    • Medium seat height helps you get on and off the trike easily.
    • Air-adjustable shock.
    • Shimano 3×9 wide range gears
    • Avid BB7 mountain disc brake x3



  • Description

    Model 320 is equipped with three 20” wheels. The small wheels decide its short wheelbase and compact structure. The small inclined angle of the seat makes it easy to get on and off. It is more suitable for heavier or less flexible riders.

  • Applications

    Commuting, traveling, exercising, rehabilitation

Go out for a ride with TrikExplor suspension recumbent trike 320E

  • Advantages

  • Specifications

  • ACCESSORIES & PARTS

  • 320 offers a clear view of traffic and good ground clearance, ideal for roads and trail use.

  • Technical Data Components
    Overall width 90 cm Frame Aluminum 6061 T6
    Overall height 91 cm Seat Ergo-mesh seat
    Overall length 185-205 cm Tires Kenda 20×1.35″
    Track width 85 cm Front brakes Avid BB7 mountain mechanical disc brake
    Wheelbase 118 cm Rear brake Avid BB7 mountain mechanical disc brake
    Ground clearance 17 cm Brake levers Avid FR-5
    Bottom seat height 37 cm Shifter Shimano Alivio SL-M4000 3×9-speed
    Seat width 37 cm Front derailleur Shimano Sora FD-3503-B
    Seat depth 25 cm Rear derailleur Shimano Alivio RD-M4000 9-speed
    Seat angle 35-45° Crankset Shimano Sora FC-3503 50-39-30T
    Turning circle 4.0 m Cassette Shimano CS-HG400-9 9-speed 11-32T
    Weight 20 kg Chain Shimano CN-HG73 9-speed
    Wheel size 20″ Suspension KS A5-Re Air Shock
    Max. load 125 kg Option (320E)
    Rider height 165-200 cm Motor 36v 250w rear hub motor
    Battery 36v 11.6 Ah lithium battery with Panasonic cells
    Display LCD display
    • Seat mesh
      Ergo-mesh seat
    • standing support scaled
      Standing support
    • review mirror
      Review mirror
    • rear rack 1
      Rear Rack
    • brake rotor
      160mm rotor
    • front hub
      Quanta hub
    • rear hub 2
      Novatec hub
    • air shock
      KS A5-Re Air Shock
